176
Effect/Parameter List
87: *DISTORTION
This effect produces a more intense distortion than Overdrive.
88: *PHASER
A phaser adds a phase-shifted sound to the direct sound,
producing a twisting modulation that creates spaciousness and
depth.
89: *SPECTRUM
Spectrum is a type of filter which modifies the timbre by
boosting or cutting the level at specific frequencies. It is similar
to an equalizer, but has 8 frequency points fixed at locations
most suitable for adding character to the sound.
90: *ENHANCER
The Enhancer controls the overtone structure of the high
frequencies, adding sparkle and tightness to the sound.
91: *AUTO WAH
The Auto Wah cyclically controls a filter to create cyclic
change in timbre.
Assignable Parameters
MFX Control
Drive, Amp Type, Pan
Parameter Value Description
Drive 0–127
Adjust the degree of distortion. The
volume will change together with the
degree of distortion.
Pan L64–0–63R
Adjust the stereo location of the output
sound. L64 is far left, 0 is center, and
63R is far right.
Amp Type
SMALL,
BUILT-IN,
2-STACK,
3-STACK
Select the type of guitar amp.
SMALL
: small amp
BUILT-IN
: single-unit type amp
2-STACK
: large double stack amp
3-STACK
: large triple stack amp
Low Gain -15– +15 dB
Adjust the gain of the low frequency
range.
Positive (+) settings will emphasize
(boost) the low frequency range.
High Gain -15– +15 dB
Adjust the gain of the high frequency
range.
Positive (+) settings will emphasize
(boost) the high frequency range.
Level 0–127
Adjust the output level.
It’s a good idea to use this parameter
to adjust the difference in volume
between when Distortion is applied
and when it is not applied.
Assignable Parameters
MFX Control
Rate, Depth, Manual
Parameter
Value Description
Manual
100–8000 Hz
Adjust the basic frequency from which
the sound will be modulated.
Rate 0.05–10.00 Hz
Adjust the frequency (period) of
modulation.
Depth 0–127 Adjust the depth of modulation.
Resonance 0–127
Adjust the amount of feedback for the
phaser.
The effect becomes more prominent as
the value is increased.
Mix 0–127
Adjust the ratio with which the phase-
shifted sound is combined with the
direct sound.
Pan L64–0–63R
Adjust the stereo location of the output
sound. L64 is far left, 0 is center, and
63R is far right.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control
Pan, Level
Parameter Value Description
Band1 (250Hz) -15– +15 dB Adjust the 250 Hz gain.
Band2 (500Hz) -15– +15 dB Adjust the 500 Hz gain.
Band3
(1000Hz)
-15– +15 dB Adjust the 1000 Hz gain.
Band4
(1250Hz)
-15– +15 dB Adjust the 1250 Hz gain.
Band5
(2000Hz)
-15– +15 dB Adjust the 2000 Hz gain.
Band6
(3150Hz)
-15– +15 dB Adjust the 3150 Hz gain.
Band7
(4000Hz)
-15– +15 dB Adjust the 4000 Hz gain.
Band8
(8000Hz)
-15– +15 dB Adjust the 8000 Hz gain.
Q
0.5, 1.0, 2.0,
4.0, 8.0
Simultaneously adjust the width of the
adjusted areas for all the frequency
bands.
Pan L64–0–63R
Adjust the stereo location of the output
sound. L64 is far left, 0 is center, and
63R is far right.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control Sens, Mix
Parameter
Value Description
Sens
0–127 Adjust the sensitivity of the enhancer.
Mix 0–127
Adjust the ratio with which the
overtones generated by the enhancer
are combined with the direct sound.
Low Gain -15– +15 dB
Adjust the gain of the low frequency
range.
Positive (+) settings will emphasize
(boost) the low frequency range.
High Gain -15– +15 dB
Adjust the gain of the high frequency
range.
Positive (+) settings will emphasize
(boost) the high frequency range.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control
Rate, Depth, Peak, Manual
Parameter
Value Description
Filter Type
LPF, BPF
Select the type of filter.
LPF
: The wah effect will be applied
over a wide frequency range.
BPF
: The wah effect will be applied
over a narrow frequency range.
Rate 0.05–10.00 Hz
Adjust the frequency of the
modulation.
Depth 0–127 Adjust the depth of the modulation.
Sens 0–127
Adjust the sensitivity with which the
filter is controlled.
Manual 0–127
Adjust the frequency from which the
effect is applied.
Parameter Value Description
