Roland SP-404MK - Front Panel

Introduction > PanelDescriptions
FrontPanel
PHONESjack
Connectyourheadphonesorearphoneshere.
1
[GAIN]knob
AdjuststheinputlevelofthedeviceconnectedtotheINPUTjack.
2
[MIC/GUITAR]switch
SwitchestheinputimpedancetomatchthedevicethatʼsconnectedtotheINPUTjack.Whenconnecting
ahigh-impedanceinstrument(suchasaguitarorbassguitar),fliptheswitchtotheright(towardsthe
INPUTjack).
3
INPUTjack
Connectanexternaldeviceorinstrumentsuchasamicrophoneoraguitarhere.
INPUTjackpinarrangement
4
