Roland TR-8S Reference Manual

10
Main Screens
TR-REC
Create a pattern by specifying the steps at
which each track plays a sound.
PTN SELECT
Select the pattern to play.
Bank Number
Variation currently
selected for recording
A–H
Name of currently playing pattern
Pattern that plays next
Name of pattern that plays next
Currently playing
pattern
Pattern that plays next
SUB
Input or perform sub steps or flams.
INST PLAY
Play pads [1] (BD)–[11] (RC) in real time.
LAST
Specify the length (last step) of a variation
or track.
INST REC
Create a pattern by realtime-recording your
performance on pads [1] (BD)–[11] (RC).

Roland TR-8S Specifications

General

USB port	Yes
Apple docking	No
USB connector type	USB Type-B
USB ports quantity	1
Compatible memory cards	SD, SDHC
Current	2 A
Power supply type	AC
Display type	LCD
Product color	Black
USB direct playback	-

Weight and Dimensions

Depth	263 mm
Width	409 mm
Height	58 mm
Weight	2100 g
