Roland V-8HD - 6: PinP

71
Menu List
6: PinP
PinP 1, 2
Menu item Value (Bold: default) Explanation
PinP SOURCE HDMI 1–8, STILL 1–8
Species the video source of the inset screen.
If MODE is “PinP 1 SOURCE” or “PinP 2 SOURCE,” you can also use the PinP SOURCE
[1]–[8] buttons to switch this.
PinP TYPE
PinP
LUMINANCE-WHITE KEY
LUMINANCE-BLACK KEY
CHROMA KEY
Species the type of PinP compositing.
* The menu items dier for each type.
9 PinP TYPE: PinP Composites the video of the inset screen on top of the background video.
Menu item Value (Bold: default) Explanation
COPY SETTINGS FROM
PinP 2 (or PinP 1)
EXEC Copies the other PinP settings.
SWAP SETTINGS FROM
PinP 2 (or PinP 1)
EXEC Exchanges the settings of PinP 1 and PinP 2.
WINDOW Adjusts the inset screen.
POSITION H -50.0–-40.0–50.0% Adjusts the inset screen’s display position horizontally.
POSITION V -50.0–-40.0–50.0% Adjusts the inset screen’s display position vertically.
SIZE 10.0–35.0–100.0% Adjusts the size (zoom) of the inset screen.
CROPPING H 0.0–100.0% Adjusts the horizontal size of the inset screen.
CROPPING V 0.0–100.0% Adjusts the vertical size of the inset screen.
SHAPE RECTANGLE, CIRCLE, DIAMOND Species the shape of the inset screen.
BORDER COLOR
WHITE, YELLOW, CYAN, GREEN,
MAGENTA, RED, BLUE, BLACK,
SOFT EDGE
Species the color of the border for the inset screen.
If this is set to “SOFT EDGE,” the edge of the inset screen is blurred.
BORDER WIDTH 0–3–14 Adjusts the width of the border for the inset screen.
VIEW Adjusts the video that is shown in the inset screen.
POSITION H -50.0–0.0–50.0% Adjusts the horizontal position at which the inset screen is shown.
POSITION V -50.0–0.0–50.0% Adjusts the vertical position at which the inset screen is shown.
ZOOM 100–400% Adjusts the zoom of the inset screen.
9 PinP TYPE: LUMINANCE-WHITE KEY
Composites the video by applying a luminance key to the PinP to make its white
areas transparent.
Menu item Value (Bold: default) Explanation
COPY SETTINGS FROM
PinP 2 (or PinP 1)
EXEC Copies the other PinP settings.
SWAP SETTINGS FROM
PinP 2 (or PinP 1)
EXEC Exchanges the settings of PinP 1 and PinP 2.
WINDOW Adjusts the inset screen.
POSITION H -50.0–-40.0–50.0% Adjusts the inset screen’s display position horizontally.
POSITION V -50.0–-40.0–50.0% Adjusts the inset screen’s display position vertically.
SIZE 10.0–35.0–100.0% Adjusts the size (zoom) of the inset screen.
CROPPING H 0.0–100.0% Adjusts the horizontal size of the inset screen.
CROPPING V 0.0–100.0% Adjusts the vertical size of the inset screen.
VIEW Adjusts the video that is shown in the inset screen.
POSITION H -50.0–0.0–50.0% Adjusts the horizontal position at which the inset screen is shown.
POSITION V -50.0–0.0–50.0% Adjusts the vertical position at which the inset screen is shown.
ZOOM 100–400% Adjusts the zoom of the inset screen.
KEY LEVEL 0–64–255 Adjusts the degree of extraction (transparency) for the key.
KEY GAIN 0–255 Adjusts the degree of edge blur (semi-transmissive region) for the key.
MIX LEVEL 0–255 Adjusts the key’s overall density (output level).
