Roland V-8HD - Page 72

72
Menu List
Menu item Value (Bold: default) Explanation
FILL TYPE BUS, MATTE
If this is “MATTE,” the superimposed logo or video is lled-in with the specied
color when using key compositing.
The ll-in color is specied by “MATTE COLOR” listed below.
MATTE COLOR
WHITE, YELLOW, CYAN, GREEN,
MAGENTA, RED, BLUE, BLACK
Species the color used when lling-in the superimposed logo or video.
* This is valid when “FILL TYPE” is set to “MATTE.”
EDGE TYPE
OFF, BORDER, DROP, SHADOW,
OUTLINE
Species the type of edge applied to the superimposed logo or video.
EDGE COLOR
WHITE, YELLOW, CYAN, GREEN,
MAGENTA, RED, BLUE, BLACK
Species the color of the edge applied to the superimposed logo or video.
EDGE WIDTH 0–3–14 Species the width of the edge applied to the superimposed logo or video.
9 PinP TYPE: LUMINANCE-BLACK KEY
Composites the video by applying a luminance key to the PinP to make its black
areas transparent.
Menu item
Value (Bold: default)
Explanation
COPY SETTINGS FROM
PinP 2 (or PinP 1)
EXEC Copies the other PinP settings.
SWAP SETTINGS FROM
PinP 2 (or PinP 1)
EXEC Exchanges the settings of PinP 1 and PinP 2.
WINDOW Adjusts the inset screen.
POSITION H -50.0–-40.0–50.0% Adjusts the inset screen’s display position horizontally.
POSITION V -50.0–-40.0–50.0% Adjusts the inset screen’s display position vertically.
SIZE 10.0–35.0–100.0% Adjusts the size (zoom) of the inset screen.
CROPPING H 0.0–100.0% Adjusts the horizontal size of the inset screen.
CROPPING V 0.0–100.0% Adjusts the vertical size of the inset screen.
VIEW Adjusts the video that is shown in the inset screen.
POSITION H -50.0–0.0–50.0% Adjusts the horizontal position at which the inset screen is shown.
POSITION V -50.0–0.0–50.0% Adjusts the vertical position at which the inset screen is shown.
ZOOM 100–400% Adjusts the zoom of the inset screen.
KEY LEVEL 0–64–255 Adjusts the degree of extraction (transparency) for the key.
KEY GAIN 0–255 Adjusts the degree of edge blur (semi-transmissive region) for the key.
MIX LEVEL 0–255 Adjusts the key’s overall density (output level).
FILL TYPE BUS, MATTE
If this is “MATTE,” the superimposed logo or video is lled-in with the specied
color when using key compositing.
The ll-in color is specied by “MATTE COLOR” listed below.
MATTE COLOR
WHITE, YELLOW, CYAN, GREEN,
MAGENTA, RED, BLUE, BLACK
Species the color used when lling-in the superimposed logo or video.
* This is valid when “FILL TYPE” is set to “MATTE.”
EDGE TYPE
OFF, BORDER, DROP, SHADOW,
OUTLINE
Species the type of edge applied to the superimposed logo or video.
EDGE COLOR
WHITE, YELLOW, CYAN, GREEN,
MAGENTA, RED, BLUE, BLACK
Species the color of the edge applied to the superimposed logo or video.
EDGE WIDTH 0–3–14 Species the width of the edge applied to the superimposed logo or video.
