Menu List
9 PinP TYPE: CHROMA KEY Composites the video by applying chroma key to the PinP.
Menu item Value (Bold: default) Explanation
COPY SETTINGS FROM
PinP 2 (or PinP 1)
EXEC Copies the other PinP settings.
SWAP SETTINGS FROM
PinP 2 (or PinP 1)
EXEC Exchanges the settings of PinP 1 and PinP 2.
WINDOW Adjusts the inset screen.
POSITION H -50.0–-40.0–50.0% Adjusts the inset screen’s display position horizontally.
POSITION V -50.0–-40.0–50.0% Adjusts the inset screen’s display position vertically.
SIZE 10.0–35.0–100.0% Adjusts the size (zoom) of the inset screen.
CROPPING H 0.0–100.0% Adjusts the horizontal size of the inset screen.
CROPPING V 0.0–100.0% Adjusts the vertical size of the inset screen.
VIEW Adjusts the video that is shown in the inset screen.
POSITION H -50.0–0.0–50.0% Adjusts the horizontal position at which the inset screen is shown.
POSITION V -50.0–0.0–50.0% Adjusts the vertical position at which the inset screen is shown.
ZOOM 100–400% Adjusts the zoom of the inset screen.
KEY LEVEL 0–64–255 Adjusts the degree of extraction (transparency) for the key.
KEY GAIN 0–255 Adjusts the degree of edge blur (semi-transmissive region) for the key.
MIX LEVEL 0–255 Adjusts the key’s overall density (output level).
CHROMA Make detailed settings for chroma key.
COLOR GREEN, BLUE
Sets green or blue as the key color (the color to be removed). If you want a color
other than green or blue to turn transparent, use “SAMPLING MARKER” to specify
the key color.
HUE WIDTH -30–0–30 Adjusts the hue width for the key color.
HUE FINE 0–240–360 Adjusts the center position of the hue for the key color.
SATURATION WIDTH -30–0–30 Adjusts the saturation width for the key color.
SATURATION FINE 0–255 Adjusts the center position of saturation for the key color.
SAMPLING MARKER OFF, ON
If this is “ON,” a sampling marker (cross-shaped cursor) is shown on the preview
output video for you to sample (detect) the key color.
When you execute sampling, the setting automatically turns “OFF.”
POSITION H -50–0–50% Adjusts the horizontal position of the sampling marker.
POSITION V -50–0–50% Adjusts the vertical position of the sampling marker.
SAMPLING EXECUTE EXEC
Executes key color sampling.
The “HUE WIDTH,” “HUE FINE,” “SATURATION WIDTH,” and “SATURATION FINE”
settings are adjusted automatically.
FILL TYPE BUS, MATTE
If this is “MATTE,” the superimposed logo or video is lled-in with the specied
color when using key compositing.
The ll-in color is specied by “MATTE COLOR” listed below.
MATTE COLOR
WHITE, YELLOW, CYAN, GREEN,
MAGENTA, RED, BLUE, BLACK
Species the color used when lling-in the superimposed logo or video.
* This is valid when “FILL TYPE” is set to “MATTE.”
EDGE TYPE
OFF, BORDER, DROP, SHADOW,
OUTLINE
Species the type of edge applied to the superimposed logo or video.
EDGE COLOR
WHITE, YELLOW, CYAN, GREEN,
MAGENTA, RED, BLUE, BLACK
Species the color of the edge applied to the superimposed logo or video.
EDGE WIDTH 0–3–14 Species the width of the edge applied to the superimposed logo or video.
