Roland VR-4HD - Dimensions

47
Appendices
 Other Connectors
RS-232 D-sub 9-pin type
Tally/GPIO Mini D-sub 15-pin type
USB 3.0/2.0 (device) USB B type, USB-VIDEO (Super-Speed), USB-AUDIO 2 IN/2 OUT (Full-Speed), remote control from PC
 Display
Graphic Color LCD, 320 x 240 dots, touch panel
 Other Functions
MEMORY (8 types), FREEZE (input video captured), OUTPUT FADE (Audio, Video: WHITE or BLACK)
 Other
Power Supply AC Adaptor
Current Draw 3 A
Power Consumption 36 W
Operation Temperature
+0 to +40 degrees Celsius
+32 to +104 degrees Fahrenheit
Dimensions
339 (W) x 217 (D) x 87 (H) mm
13-3/8 (W) x 8-9/16 (D) x 3-7/16 (H) inches
Weight
(excluding AC adaptor)
2.4 kg
5 lbs 5 oz
Accessories Owner’s manual, AC adaptor, Power cord
* 0 dBu=0.775 Vrms
* This document explains the specications of the product at the time that the document was issued. For the latest information, refer to the Roland website.
Dimensions
339
87
70
217
210
215
7
Unit: mm
