Roland VR-4HD - Appendices - Technical Specifications (Video & Audio); Video Specifications; Audio Specifications

46
Appendices
Main Specications
 Video
Video Processing 4:2:2 (Y/Pb/Pr), 8-bit
Input Connectors
INPUT 1–3 HDMI Type A (19 pins) x 3 * HDCP Supported
INPUT 4
HDMI Type A (19 pins) x 1 * HDCP Supported
RGB/COMPONENT (Mini D-sub 15-pin type) x 1
COMPOSITE (RCA phono type) x 1
* INPUT 4: HDMI , RGB/COMPONENT or COMPOSITE selected.
Output Connectors
MAIN OUT
HDMI Type A (19 pins) x 1 * HDCP Supported
RGB/COMPONENT (Mini D-sub 15-pin type) x 1
PREVIEW OUT HDMI Type A (19 pins) x 1 * HDCP Supported
USB 3.0 USB B type x 1
Input formats
*1 *2
HDMI INPUT 1–3
720/59.94p, 720/50p (SYSTEM FORMAT: 720p)
1080/59.94i, 1080/50i, 1080/59.94p, 1080/50p (SYSTEM FORMAT: 1080i, 1080p)
INPUT 4
HDMI
RGB/COMPONENT
480/59.94i, 576/50i, 480/59.94p, 576/50p, 720/59.94p, 720/50p, 1080/59.94i, 1080/50i, 1080/59.94p, 1080/50p
VGA (640 x 480/60 Hz), SVGA (800 x 600/60 Hz), XGA (1024 x 768/60 Hz), WXGA (1280 x 768/60 Hz),
SXGA (1280 x 1024/60 Hz), FWXGA (1366 x 768/60 Hz), SXGA+ (1400 x 1050/60 Hz), UXGA (1600 x 1200/60 Hz) ,
WUXGA (1920 x 1200/60 Hz)
* The refresh rate is the maximum value of each resolution.
* Conforms to VESA DMT Version 1.0 Revision 11.
* 1920 x 1200/60 Hz: Reduced blanking
COMPOSITE 480/59.94i, 576/50i
Output formats
*2
MAIN OUT
(HDMI, RGB/COMPONENT)
480/59.94i, 576/50i, 480/59.94p, 576/50p, 720/59.94p, 720/50p, 1080/59.94i, 1080/50i, 1080/59.94p, 1080/50p
VGA (640 x 480/60 Hz), SVGA (800 x 600/60 Hz), XGA (1024 x 768/60 Hz), WXGA (1280 x 768/60 Hz),
SXGA (1280 x 1024/60 Hz), FWXGA (1366 x 768/60 Hz), SXGA+ (1400 x 1050/60 Hz), UXGA (1600 x 1200/60 Hz) ,
WUXGA (1920 x 1200/60 Hz)
* The MAIN OUTPUT format of HDMI and RGB/COMPONENT is always the same.
When an interlaced format is selected, component signal is output from the RGB/COMPONENT connector.
When a non-interlaced format is selected, RGB signal is output from the RGB/COMPONENT connector.
PREVIEW OUT
720/59.94p, 720/50p (SYSTEM FORMAT: 720p)
1080/59.94i, 1080/50i (SYSTEM FORMAT: 1080i)
1080/59.94p, 1080/50p (SYSTEM FORMAT: 1080p)
USB 3.0
720/29.97p, 720/25p (SYSTEM FORMAT: 720p)
1080/29.97p, 1080/25p (SYSTEM FORMAT: 1080i, 1080p)
Video Eects
Transition CUT, MIX (DISSOLVE/FAM/NAM/MOSAIC), WIPE (30 types)
Eects NEGATIVE, EMBOSS, COLORIZE, COLORPASS, POSTERIZE, SILHOUETTE, MONOCOLOR, FINDEDGE (8 types)
Composition PinP, SPLIT, QUAD, KEY (Luminance Key, Chroma Key)
*1: The input interlaced video signal is converted to progressive video signal by internal processing.
*2: The video signal frame rate can be selected at the SYSTEM menu (59.94 Hz or 50 Hz).
 Audio
Audio Processing Sampling rate 24 bits/48 kHz
Audio formats
HDMI Linear PCM, 24 bits/48 kHz, 2 ch
USB Linear PCM, 16 bits/48 kHz, 2 ch
Input Connectors
AUDIO IN 1–4 XLR/TRS combo type, phantom power
AUDIO IN 5–6 RCA phono type
AUDIO IN 7/8 Stereo miniature type
USB USB B type (stereo)
Phantom Power DC 48 V (unloaded maximum), 10 mA (maximum load) * Current value per channel
Output Connectors
AUDIO OUT
L, R (XLR type)
L, R (RCA phono type)
AUX OUT L, R (RCA phono type)
USB USB B type (stereo)
PHONES Stereo miniature type
Signal Level and
Impedance
XLR/TRS combo type
Input Signal Level -60–+4 dBu (Maximum: +22 dBu)
Input Impedance 10 k ohms (GAIN 0–23 dB), 5 k ohms (GAIN 24–64 dB)
RCA phono type
Input Signal Level -10 dBu (Maximum: +8 dBu)
Input Impedance 15 k ohms
Output Signal Level -10 dBu (Maximum: +8 dBu)
Output Impedance 1 k ohm
XLR type
Output Signal Level +4 dBu (Maximum: +22 dBu)
Output Impedance 600 ohms
Miniature type
Input Signal Level -15 dBu (Maximum: +3 dBu)
Input Impedance 15 k ohms
Headphones
Output Signal Level 75 mW + 75 mW
Output Impedance 32 ohms
Audio Eects Auto Mixing, Echo Cancel, EQ, Delay, Compressor, HPF, Gate, Reverb, Multi-Band Compressor, Limiter
Roland VR-4HD: HD AV Mixer
