Ross Carbonite Series Setup Manual

• 480i
• 576i
• 720p 59.94
• 720p 50
• 1080i 59.94
• 1080i 50
To Set Up an Analog Input
1.
Press MENU > CONFIG > Input > NEXT >
NEXT > NEXT > NEXT.
2.
Use the Input knob to select MultiMedia input
you want to set up as an Analog input.
3.
Use the Type knob to select the type of analog
input.
•
Compos — composite video format
•
Compon — component video format
4.
If you selected component as the input type, use
the Format or F/Frmt knob to select the video
format of the component input.
5.
If you selected composite as the input type, press
the F/Frmt knob.
6.
Use the Frming or Fram/F knob to select the
aspect ratio conversion you want to use.
•
Full — The video signal is scaled
disproportionately to ll the display of the
new aspect ratio. Aspect distortion occurs as
the image is stretched/compressed to t in
the new aspect ratio.
•
Zoom — The central portion of the video
signal is zoomed to ll the display of the new
video format. No aspect distortion is
introduced but the edges of the video signal
may be cropped.
•
LttrBx — Black bars are added to the top
and bottom of a 16:9 image to display
correctly in a 4:3 video format.
•
PllrBx — Black bars are added to the right
and left of a 4:3 image to display correctly
in a 16:9 video format.
Auto Key Setup
An auto key allows you to associate a key alpha with a
key video source in the switcher. When the video source
is selected as a keyer, the key alpha is automatically used.
To Set Up an Auto Key Association
As well as input sources, internally generated sources,
such as media-stores and color backgrounds, can be set
up as an auto key.
1.
Press MENU > CONFIG > Input.
2.
Use the Mnemnc knob to select the key video
source that you want to assign an alpha to.
3.
Use the Alpha knob to select the key alpha
source that you want to assign to the key video.
•
<none> — no alpha
•
White — assign a white background as a
key alpha
•
Input BNC — assign the source on the
selected input as a key alpha
•
BK — assign internal black as a key alpha
•
BG — assign the matte generator as a key
alpha
•
MX — assign the source on Media-Store X
as a key alpha
•
MEX — assign the program output of ME X
as the key alpha
•
MEX PV — assign the preview output of
ME X as the key alpha
•
MEX PV — assign the clean feed output of
ME X as the key alpha
•
MiniMEX — assign the output of MiniME
™
X as the key alpha
4.
Use the Mode knob to select whether the alpha
is shaped Shaped, or unshaped (Linear).
•
Linear — the alpha cuts a hole based on the
gradient values of the alpha (gray)
•
Shaped — the alpha cuts a hole based on
the monochrome value of the alpha (black or
white)
Source Names
Each video source on the switcher can be given a unique
name that is used on the mnemonics for that source, as
well as internal menus. These names can be customized
for how they appear on the mnemonics by adjusting the
size or the font and the background color.
Note: If a TSL ID is assigned to a source, the switcher
overwrites the source name on the MultiViewer and mnemonics
with the TSL name. If there is no TSL name, or it has not been
received yet, the source name is blank. For the labels on the
MultiViewer, a combination of the TSL name and switcher
20 • Video Input Setup — Carbonite Setup Manual (v10.0)
