Switcher Resources
The switcher has a number of resources that it must share
across keyers or MEs. How these resources are shared,
and what happens when a resource is needed by another
keyer or ME can be set to ask if you want to steal the
resource from another keyer or ME, oat the resources
across all keyer and MEs, or lock the resources to a
particular keyer or ME.
Switcher Resources
Note: Memory Recall Mode cannot be set to MemAI or Memory
to be able to set the resource sharing.
1.
Press MENU > SYSTEM > Rsrc Mode.
2.
Use the Resrc knob to select the resource that
you want to assign.
•
CRKEYX — UltraChrome chroma keys
•
DVEX — DVE channels
3.
Use the Mode knob to select how the resource
is assigned.
•
MX:KX — assign to specic ME keyer
•
MMX:KX — assign to specic MiniME
™
keyer
•
MX:TR — assign to specic ME transition
area
•
MMX:TR — assign to specic MiniME
™
transition area
•
FLOAT — oat across all ME/MiniME
™
outputs and keyers (you are prompted to take
resources if a resource is already in use by
another on-air key)
•
ASK — oat across all ME/MiniME
™
outputs and keyers (you are prompted to take
the resource if a resource is already in use by
another on-air, or off-air key)
If a chroma key resource is being taken from a
keyer, the key type is changed to Auto Select
and it is cut off-air.
4.
Press the Mode knob.
5.
Press the Confrm knob to accept the new
resource settings.
DVE Resource Capture
Capturing a DVE resource for a new key or transition
takes the DVE resources from the following sources in
order of availability:
1.
Transition Area — if a DVE transition is not in
progress
2.
Off-Air DVE key — highest number resource is
taken rst
3.
On-Air DVE key — current DVE Key is converted
to an Auto-Select key and taken off-air
4.
Transition Area — if a DVE transition is in
progress, the transition is converted to a dissolve
Chroma Key Resource Capture
Capturing a Chroma Key resource for a new key causes
the following to occur:
• The current Chroma Key is converted to an
Auto-Select Key
• If the current Chroma Key is on-air, it is taken
off-air
38 • Switcher Resources — Carbonite Setup Manual (v10.0)
