Ross Carbonite Series Setup Manual

Specifications
The information is this section is subject to change
without notice.
Operating Temperature
The Carbonite switchers have been qualied at an
operational temperature range of 0-40°C (32-140°F).
Video Input Specifications
ValueInput Specification
>50m @ 3Gb/sEqualization (using Belden
1694 cable)
>100m @ 1.5 Gb/s
>300m @ 270 Mb/s (5°-40°C)
75 ohms, terminatingImpedance
SMPTE 259M/292M/424M
serial digital (non-looping)
Video Inputs, SDI
HDMI 1.4Video Inputs, HDMI
High Speed HDMI Cable (Max
10m)
Input Impedance — 75 OhmVideo Inputs, Analog
Levels — 1V peak-to-peak,
nominal
Standard Definition — analog
black
Reference Inputs
(non-terminating, looping
High Definition — tri-level sync
Video Output Specifications
ValueOutput Specification
<-23dB @ 1.5GHzReturn Loss
<-18dB @ 3GHz
800ps ±10% (SD)Rise and Fall Time
240ps ±10% (HD)
800mV ±10%Signal Level
0 VoltsDC Offset
<10%Overshoot
10-bit SMPTE-292M/424M
serial digital
HD Mode
Audio Specifications
ValueSpecification
24-bit AES3 in HD (20-bit in
SD)
Audio Depth
48kHzSample Rate
8 Stereo Pairs (16 channels)Channels
Locked to VideoSynchronization
Multi-channel Waveform Audio
File (.wav)
File Format
Power Rating
Table 9: Input Voltage
Power RatingComponent
100-120V~Panel
220-240V~
47-63Hz
Table 10: Power Consumption
Power ConsumptionComponent
24W 2.0A 12VC10
24W 2.0A 12VC1
30W 2.5A 12VC1-A
30W 2.5A 12VC1M
42W 3.5A 12VC2
50W 4.2A 12VC2M
54W 4.5A 12VC2S
65W 5.5A 12VC2X
66W 5.5A 12VC3S
84W 7.0A 12VC3X
90W 7.5A 12VFrame, Carbonite
Serial Port
• 38.4k Baud
• 8 bits
• 1 stop bit
• Even Parity
Table 11: Serial Port Pinouts
SignalPin
Tx+1
Carbonite Setup Manual (v10.0) — Specifications • 49
USO RESTRITO
