Ross Carbonite Series Setup Manual

Network Connections
The switcher is equipped with two Ethernet ports to allow
remote access. Once the Ethernet ports are set up, you
can connect to the switcher over FTP to upload stills to
the Media-Store channels, as well as download switcher
data les.
The switcher does not require an IP address to operate.
Network Setup
Setting up a network connection allows you to connect
to the switcher remotely. By default, the switcher uses
DHCP to automatically obtain an IP address. You can
manually set a static IP address, network mask, and
default gateway if your network does not have a DHCP
server.
To View the Current Network Settings
Tip: Network settings can also be set from the Network tab
on the Configuration node in DashBoard.
1.
Press MENU > SYSTEM > NEXT > NEXT IP
Addr.
2.
Use the left knob to view the current network
setting.
•
X-Addr — IP address for network port 1 or
2
•
X-Mask — network mask for network port
1 or 2
•
X-MAC — MAC address for network port
1 or 2
•
Gatwy — gateway for both network ports
To Set an IP Address Using DHCP
Due to the nature of DHCP, your switcher may get a
different IP address each time it is powered on or
re-connected to a network. You must have the switcher
connected to a network to be able to obtain an IP address
using DHCP.
Tip: Network settings can also be set from the Network tab
on the Configuration node in DashBoard.
1.
Ensure that DIP switch 3 on the frame is set in
the up position. If this DIP switch is set in the
down position, the IP address is xed at
192.168.0.123.
2.
Press MENU > SYSTEM > NEXT > NEXT >
IP Addr.
3.
Use the left knob to select the network port that
you want to set to DHCP. Only one port can be
set to DHCP at a time.
•
1-Mode — network port 1
•
2-Mode — network port 2
4.
Press the Edit knob.
5.
Use the Value knob to select DHCP.
6.
Press the Value knob.
7.
Press the Reboot knob to restart the switcher
in DHCP mode.
The switcher will request an IP address when it
restarts.
To Set a Static IP Address
You must have the switcher connected to a network to
be able to set a static IP. If the switcher is not connected
to a network, the switcher does not display the IP address.
Tip: Network settings can also be set from the Network tab
on the Configuration node in DashBoard.
1.
Ensure that DIP switch 3 on the frame is set in
the up position. If this DIP switch is set in the
down position, the IP address is xed at
192.168.0.123.
2.
Press MENU > SYSTEM > NEXT > NEXT IP
Addr.
3.
Use the left knob to select the network port that
you want to set a static IP address for.
•
1-Mode — network port 1
•
2-Mode — network port 2
4.
Press the Edit knob.
5.
Use the Value knob to select Static.
6.
Press NEXT.
7.
Use the left knob to select 1-Addr for port 1 or
2-Addr for port 2.
a)
Use the Field knob to select the segment in
the address that you want to change.
b)
Use the Value knob to select the new value
you want to use for that segment.
8.
Use the left knob to select 1-Mask for port 1 or
2-Mask for port 2.
40 • Network Connections — Carbonite Setup Manual (v10.0)
