2.
Use the MemBtn knob to select whether both
of the store and recall buttons act together
(Single), or as separate ME specic buttons
(Indiv).
Memory Recall Behavior (C10/C1)
The switcher can be set to select the current ME as the
ME memories are recalled on by default.
To Set the Memory Recall Behavior
1.
Press MENU > PERS > NEXT.
2.
Use the MESel knob to select how you want
memories to recall.
•
Hold — you must select the ME that the
memory is recalled on
•
Follow — memories are recalled on the ME
selected on the control panel
Next Button Secondary Function
You can congure the NEXT button to allow you to
manually trigger GPI outputs. This allows you to use the
GPI to manually roll a clip on a video server, or load the
next page on a character generator. Refer to the External
Device Setup Sheets for more information on setting up
an using external devices.
Refer to GPI Control on page 42 for more information
on setting up and using GPIs.
To Set the NEXT Button Secondary Function
1.
Press MENU > PERS > NEXT > NEXT >
NextBn Func2.
2.
Use the Func knob to select the second function
of the Next button.
•
<none> — no secondary function
•
GPO — you can manually trigger a GPI
output
Next Transition Follow
You can have the key bus follow the next transition
selection buttons (BKGD and KEY 1-4). When set to
follow, pressing a KEY button in the next transition area
has the switcher assign the key bus and menu system to
that keyer. When set to no follow, the key bus is not
changed by selections in the next transition area.
To Set the Next Transition Follow Behavior
1.
Press MENU > PERS > NEXT > NEXT >
Trans Area.
2.
Use the NextTr knob to select whether the
switcher follows the next transition area or not.
•
NoFllw — switcher is not changed by
selection of next transition include buttons
(BKGD or KEY 1-4)
•
Follow — switcher assigns the menu and
key bus to the next transition include buttons
as they are pressed
Next Transition Reset
You can have the transition area reset to a default
background dissolve after each transition. This allows
you to prevent the selections from the last transition from
being accidentally included with the next transition.
To Set the Next Transition Reset Behavior
1.
Press MENU > PERS > NEXT > NEXT >
Trans Area.
2.
Use the Trans knob to select whether the
transition area is reset after a transition.
•
NotRst — area is not changed after a
transition
•
Reset — area is reset to a background
dissolve after each transition
Power-Save Mode
The switcher goes into a Power-Save mode after a
user-dened amount of time (20 minutes by default)
without user interaction. Touching any button, knob, or
fader will wake the switcher. The switcher does not act
on the button, knob, or fader control that wakes it from
sleep mode.
During Power-Save mode, video related hardware is not
affected and video signals still pass through the switcher.
To Set the Power Save Mode and Timer
1.
Press MENU > PERS > NEXT > NEXT.
2.
Press the Sleep/PwrSve knob to toggle
between the power save modes.
•
Sleep — displays are turned off and buttons
light in raindrop pattern
•
PwrSve — all buttons and displays are
turned off and as much power is conserved
as possible
36 • Switcher Personality — Carbonite Setup Manual (v10.0)
