Switcher Personality
There are a number of settings for how the switcher will
react to different situations, or how switcher elements
appear to the operator. All these settings are grouped
together into the Switcher Personality. These settings
include double-press rates and sleep time, among others.
Auto Remove Key
You can have a key removed from the Next Transition
area, so that it is not included in the next transition, after
it has been transitioned off-air using the KEY X CUT or
KEY X AUTO buttons. This allows you to transition a
key off-air in an emergency and not have it accidentally
transitioned back on-air with the next transition from the
Transition Area.
To Set the Auto Remove Key Behavior
1.
Press MENU > PERS > NEXT > NEXT >
Trans Area.
2.
Use the RemKey knob to select whether a key
remains selected in the Next Transition Area
(Off) after a KEY X CUT or KEY X AUTO
transitions the key off-air, or is removed from
the Next Transition Area (On).
Auto Trans Second Press
When you press the AUTO TRANS or KEY AUTO
button during a transition, the switcher can be set to either
halt the transition (the transition freezes on-air) and wait
for the button to be pressed again, immediately reverse,
or immediately cut the transition back to the initial state.
When the transition is halted, pressing the AUTO
TRANS, or KEY AUTO, button again can be set to
either continue the transition, or reverse the transition
back to the initial state.
To Set the Auto Trans Second Press Behavior
1.
Press MENU > PERS > NEXT > NEXT >
Trans Area > NEXT.
2.
Use the MAuto 2, or KAuto 2, knob to select
what happens when the AUTO TRANS, or a
KEY AUTO, button is pressed during a
transition.
•
HltFwd — the transition is halted and then
continues in the same direction when the
transition button is pressed again
•
HltRev — the transition is halted and then
reverses directions when the transition button
is pressed again
•
Rev — the transition immediately reverses
directions when the transition button is
pressed
•
Cut — the transition immediately cuts back
to the initial state when the transition button
is pressed
•
Ignore — the button press is ignored by the
switcher and the transition continues
Background Double-Press
The Background Double-Press feature allows you to have
a double-press of the BKGD button on a Transition
Module select background and all on-air keyers as part
of the next transition.
To Set the Background Double-Press Behavior
1.
Press MENU > PERS > NEXT > NEXT >
Trans Area > NEXT > NEXT.
2.
Use the BGDDbl knob select how you want
double-press the BKGD button on the transition
area to behave.
•
Ignore — ignore the on-air keyers
•
TrsClr — include all on-air keyers with the
next transition
Color Schemes
The buttons on the control panel can be set to glow with
different colors. This color can be picked from a list of
pre-set color schemes, or a custom color can be selected.
Up to four (4) custom color schemes can be saved on the
switcher.
To Select a Panel Color Scheme
The color scheme sets the glow color for the buttons on
the control panel. Each ME can be set with a different
glow color.
1.
Press MENU > USER > Scheme.
2.
Press NEXT.
3.
Use the Load knob to select the color scheme
you want to use.
If you have created custom color schemes, you
can select it from the menu.
4.
Press the Load knob.
34 • Switcher Personality — Carbonite Setup Manual (v10.0)
