a)
Use the Field knob to select the hours,
minutes, or seconds that you want to adjust.
The timecode is shown in the
[HH:MM:SS]> format.
b)
Use the Value knob to set the starting time
in the selected eld.
LiveEDL Data Capture
Capturing EDL data is manually started and stopped from
the switcher. When you select to start capturing EDL
data, and GPI outputs set to trigger on start are triggered.
If a pre-delay has been set for the GPIs, the switcher does
not start capturing EDL data until the pre-delay time has
nished.
When you stop capturing EDL data, you have the option
to delete the data, or save it to a USB drive. You can also
connect to the switcher via FTP and download the les
directly to your editing suite. Use the username
liveedl and password password to create the FTP
connection to the switcher.
Keep the following in mind when reviewing the EDL
data from the switcher:
• When a MediaWipe is selected as the transition
type, the switcher records the transition duration
as the cut point frame multiplied by two (2). This
is to ensure that the cut point is recorded accurately.
• If you used more than one ME, or Aux bus, in your
shot, a separate EDL le is saved for each ME and
Aux bus. The ME re-entry is shown as being
selected on the rst ME, and the source selections
on the second ME are saved to the separate
LiveEDL le. Aux bus information is only stored
to a LiveEDL le when the Aux bus is not in xed
mode.
To Start Capturing EDL Data
The EDL data can be stored to one of 1000 LiveEDL
les stored on the switcher. A separate le is created for
each ME when the additional MEs are used.
1.
Press MENU > USER > LiveEDL.
2.
Use the Start knob to select the LiveEDL le
on the switcher that you want to store the EDL
data to.
If the LiveEDL le already contains data, you
are given the option to delete the data, or save it
to a USB.
3.
Press the Start knob to start recording.
To Stop Capturing and Save EDL Data
1.
Press MENU > USER > LiveEDL.
2.
Press the Stop knob to stop recording.
3.
Save the EDL data to a USB as follows:
a)
Insert your USB drive into the USB Port on
the switcher. You must wait 5 seconds for
the switcher to recognise the USB drive.
b)
Press the Save knob.
c)
Press the Confrm knob to store the LiveEDL
le to the USB drive.
Carbonite Setup Manual (v10.0) — Live Edit Decision Lists • 45
