Color Correction
Color correction in the switcher is performed by either
Processing Ampliers (Proc Amps) in the HSL
(Y-Cr-Cb) color space or by RGB Color Correctors in
the RGB color space. Both Proc Amps and RGB Color
Correctors allow you to apply color correction to video
sources, before the crosspoint. Corrected video is then
available to all MEs.
Color correction is additive, allowing you to apply any
combination of Proc Amp and RGB Color Corrector
based adjustment to a video signal. If multiple color
corrections are applied, the correction is applied rst,
and the bus-based correction is applied after that.
Proc Amp Color Correction
(Carbonite+ and Carbonite
MultiMedia Only)
The Proc Amp video correction allows you to adjust the
gain, offset, black level, and gamma of the video signal.
To Apply a Proc Amp to a Video Source
1.
Double-press the source button for the input
video source you want to apply the Proc Amp
to.
If a device is assigned to the video source, you
may have to press NEXT to view the correct
page.
Tip: If correction has already been applied (ON), press
Reset to return the Proc Amp and Color Correction to
the default values.
2.
Press the PrcAmp knob.
Tip: You can return the Proc Amp adjustment to the
default settings by using the Cntrl knob to select Reset
and press the Perfrm Reset knob.
3.
Adjust the overall gain as follows:
a)
Use the Cntrl knob to select Gain.
b)
Use the Value knob to adjust the
chrominance and luminance gain together.
4.
Adjust the chrominance gain as follows:
a)
Use the Cntrl knob to select ChGain.
b)
Use the Value knob to adjust the
chrominance gain only.
5.
Adjust the luminance gain as follows:
a)
Use the Cntrl knob to select LmGain.
b)
Use the Value knob to adjust the luminance
gain only.
6.
Adjust the hue rotation as follows:
a)
Use the Cntrl knob to select HueRot.
b)
Use the Value knob to adjust the Hue.
Increasing the Hue Rotation turns the color
wheel clockwise, and decreasing the Hue
Rotation turns the color wheel
counter-clockwise.
7.
Adjust the black level as follows:
a)
Use the Cntrl knob to select BlkLvl.
b)
Use the Value knob to adjust the black level.
Black level acts as a luminance offset.
8.
Adjust the gamma value as follows:
a)
Use the Cntrl knob to select GamVal.
b)
Use the Value knob to adjust the luminance
gamma value.
9.
Adjust the gamma offset as follows:
a)
Use the Cntrl knob to select GamOff.
b)
Use the Value knob to adjust the luminance
gamma offset.
10.
Adjust the Cr (red color difference) gain as
follows:
a)
Use the Cntrl knob to select CrGain.
b)
Use the Value knob to adjust the gain of the
Cr.
11.
Adjust the Cr (red color difference) offset as
follows:
a)
Use the Cntrl knob to select CrOff.
b)
Use the Value knob to adjust the offset of
the Cr.
12.
Adjust the Cb (blue color difference) gain as
follows:
a)
Use the Cntrl knob to select CbGain.
b)
Use the Value knob to adjust the gain of the
Cb.
13.
Adjust the Cb (blue color difference) offset as
follows:
a)
Use the Cntrl knob to select CbOff.
30 • Color Correction — Carbonite Setup Manual (v10.0)
