5.
Use the Transp knob to adjust the transparency
of the background behind the source label for
the selected MultiViewer.
6.
Press NEXT.
7.
Use the Ovrlay knob to select a video source
that you want to overlay over the MultiViewer
output.
Tip: The overlay source can be used to overlay a
camera shot of a shot-clock over the MultiViewer
output.
8.
Use the Clip knob to adjust the clipping of the
overlay source.
At 0% the overlay source is completely opaque,
and at 100% it is completely transparent.
9.
Press NEXT.
10.
Use the AncSrc knob to select where the
ancillary data, including embedded audio, fed
out with the MultiViewer comes from.
•
<none> — no source is selected
•
M1-M2 — Media-Store channels
•
MEXMW — ME X Media Wipe video
11.
Use the Tally knob to select how boxes on the
MultiViewer are tallied.
•
Box — red or green border is shown around
the outside of the MultiViewer box
•
Label — red or green boxes are shown
inside the label area of the MultiViewer box
•
LblRev — the same as Label, but the
placement of the tally boxes is swapped
12.
Press NEXT.
13.
Use the FSLBL knob to select whether FSFC is
shown on the source labels (On) or not (Off)
when a FSFC is applied to the source.
14.
Press NEXT.
15.
Use the Box knob to select the box on the
MultiViewer grid that you want to congure.
For example, MV1:4 is box 4 on MultiViewer
1, and MV2:3 is box 3 on MultiViewer 2.
16.
Use the In/Out knob to select the source or bus
you want to assign to the box.
When you assign an output to a box, the switcher
routes the source selected on that bus to the box,
and not the output of the bus.
17.
Use the Border knob to turn the border around
the MultiViewer box off (Off), white (White),
or black (Black).
When the border is turned off, some distortion
may be visible around the edges of the box.
18.
Press NEXT.
19.
Use the Marker knob to turn aspect ratio
markers for the MultiViewer box on (Aspect)
or off (Off).
20.
Use the Label knob to turn source labels for the
MultiViewer box off, or on in a selected position
(Bottom or Top).
21.
Press NEXT.
22.
Use the GrnTly knob to turn the preview (green)
tally for the MultiViewer box on or off.
23.
Use the RedTly knob to turn the program (red)
tally for the MultiViewer box on or off.
24.
Press NEXT.
25.
Use the MScrnX knob to turn the MultiScreen
overlay on (On), or off (Off). The overlay shows
what portions of the image are cropped out to t
into the output of the MultiScreen.
26.
Congure additional MultiViewer boxes as
required.
To Set Up a MultiViewer Clock
1.
Press MENU > SYSTEM > MultiView > NEXT
> NEXT > NEXT > Edit Clock.
2.
Use the Clock knob to select the clock source
to display.
•
Off — turns the clock off
•
Tmcode — displays the timecode fed to the
switcher (hh:mm:ss:ff)
•
System — displays the system time of the
switcher in 12-hour or 24-hour format
(hh:mm:ss)
3.
For a Timecode clock, use the LTCFrm knob
to select whether the number of frames for a
timecode is displayed (On) or not (Off).
4.
For a System clock, use the Format knob to set
how the time is displayed.
•
24h — time is displayed in 24-hour format.
•
12h — time is displayed in 12-hour format
without am/pm.
•
AM/PM — time is displayed in 12-hour
format with am/pm.
26 • Video Outputs — Carbonite Setup Manual (v10.0)
