SignalPin
Tx-2
Rx+3
n/c4
n/c5
Rx-6
Ground7
Ground8
GPI Port
The GPI I/O port on the back of the frame supports 34
GPI I/O pins.
Table 12: GPI I/O Pinouts
SignalPin
GPI I/O 11
GPI I/O 22
GPI I/O 33
GPI I/O 44
GPI I/O 55
GPI I/O 66
GPI I/O 77
GPI I/O 88
GPI I/O 99
GPI I/O 1010
GPI I/O 1111
GPI I/O 1212
GPI I/O 1313
GPI I/O 1414
GPI I/O 1515
GPI I/O 1616
GPI I/O 1717
GPI I/O 1818
GPI I/O 1919
GPI I/O 2020
GPI I/O 2121
GPI I/O 2222
GPI I/O 2323
GPI I/O 2424
Ground25
SignalPin
GPI I/O 2526
GPI I/O 2627
GPI I/O 2728
GPI I/O 2829
GPI I/O 2930
Ground31
GPI I/O 3032
GPI I/O 3133
GPI I/O 3234
GPI I/O 3335
GPI I/O 3436
n/c37
Tally Port
Table 13: Tally Rating
ValueSpecification
24VAC(rms)/40VDCInput Voltage
120mAMaximum Current
<15 ohmImpedance
50 • Specifications — Carbonite Setup Manual (v10.0)
