5.
Press the Confrm knob.
To Create a Custom Panel Color Scheme
Custom colors are created using standard hue, saturation,
and luminance values. Once created, you can save your
custom color.
1.
Press MENU > USER > Scheme.
2.
Use the Hue knob to adjust the hue of your
custom color.
3.
Use the Sat knob to adjust the saturation of your
custom color.
4.
Use the Lum knob to adjust the luminance of
your custom color.
5.
Press NEXT > NEXT.
6.
Use the Save knob to select the custom scheme
that you want to store the custom color to.
7.
Press the Save knob.
8.
Press the Confrm knob.
To Set the Brightness of the Control Panel
Buttons
Note: Brightness is not stored with the color scheme.
1.
Press MENU > USER > Scheme > NEXT >
NEXT > NEXT.
2.
Use the Brightness knob to set the brightness
of the buttons on the control panel.
Double-Press Rate
You can set the double-press rate of the switcher to suit
your preference. Setting a fast rate requires you to
double-press the knobs in quick succession in order to
be recognized as a double-press. Setting a slow rate
allows more time between presses but may register two
single presses as a double-press.
To Set the Double-Press Rate
1.
Press MENU > PERS > DblPrs Speed.
2.
Double-press the HERE knob at the rate you
want to use for double-pressed on the switcher.
3.
Press MENU to store the new rate.
Editor Mode
The switcher can be controlled by an external editor. The
external editor can control the switcher to perform
transitions, or recall memories, among the supported
commands.
Refer to the GVG100 Supported Protocol Document
for a list of supported commands.
To Set the Switcher to Editor Mode
Tip: You can quickly turn off editor mode by pressing and
holding the MENU button and pressing PERS.
1.
Press MENU > PERS.
2.
Use the Editor knob to select On to allow the
switcher to be controlled by an external editor.
Memory Bank Button Behavior
(C2S/C2X/C3S/C3X)
The Memory Bank Button Behavior feature allows you
to set how the BANK button behaves when pressed and
released.
To Set the Bank Button Behavior
1.
Press MENU > PERS > NEXT.
2.
Use the MemBnk knob to select how you want
the BANK button to behave when pressed and
released.
•
Normal — the keypad is used to enter the
bank number directly, followed by the
memory (For example, to access memory 3
on bank 2, press BANK > 2 > 3.)
•
Legacy — the next bank is selected every
time the button is pressed, cycling through
all banks (For example, to access bank 5,
press BANK repeatedly until bank 5 is
selected.)
Memory Button Behavior (Not
available on C1-A or C10)
The store and recall buttons next to the display can be
set to either select ME 1 or ME 2 directly, or select the
list of MEs, MiniME
™
s, or MultiScreens. This is useful
if you do not want the pressing of a store or recall button
to select or de-select an ME. The selection of what is
included in the memory store or recall is done by pressing
and holding either of the store or recall buttons and
selecting the source buttons on the keyer bus for the MEs,
MiniME
™
s, or MultiScreens you want to include.
To Set the Memory Button Behavior
1.
Press Store > NEXT > NEXT.
Carbonite Setup Manual (v10.0) — Switcher Personality • 35
