14. Default Menu
LOCAL
ST CUS
LOCAL
LD FAC
14.1 Default Menus
Set the actuator to LOCAL control to access menu.
Use the Enter/Cancel pushbuttons to select Customer or
Factory default options.
Select Edit mode and ENTER to load the selected defaults.
LD CUS
LD CUS - LOAD CUSTOMER DEFAULTS
Select EDIT mode and press ENTER.
The CONFRM parameter is now displayed, press ENTER to
return the actuator to the stored customer defaults.
ST CUS
ST CUS - SAVE CURRENT SETTINGS
Select EDIT mode and press ENTER.
The CONFRM parameter is now displayed, press ENTER to
save the current settings to the actuators customer default
memory.
LD FAC
LD FAC - LOAD FACTORY DEFAULTS
Select EDIT mode and press ENTER.
The CONFRM parameter is now displayed, press ENTER to
restore factory defaults.
LOCAL
DEFLTS
LOCAL
EDIT
CONFRM
LOCAL
LD CUS
STALL TIME
CPT 20
CMD SRCE
CPT 4
INFO
SPLT RANGE
RELAYS
ACT CFG
ADVANCED
POSIT
Position
SET PT
Setpoint
THRUST or TORQUE
Thrust or Torque
LOCREM
Local / Remote Control
MANJOG
Manual Jog
CL LIM
Close Limit (zero)
OP LIM
Open Limit (span)
CFG
Control Setup
CMD4
Field Command Signal4
CMD20
Field Command Signal20
DBAND
Deadband
FLTHST
Fault History Access
ADVANC
Advanced Menu
DEFLTS
Default Menu Access
STATUS
BASIC
INFO
ACT STS
AMP STS
TEMP
SWR VER
CTR SETUP
CTRLAL
IN DMP
LOS TO
LOS ACT
LOS LOW
LOS HI
TORQ O
TORQ C
CL ACT
OP ACT
RELAYS
RLY1 CFG
RLY1 POS
RLY1 FRM
RLY2 CFG
RLY2 POS
RLY2 FRM
ACT CFG
ACT TYPE
ACT SIZE
ENCOD IN
ASRACT
SP RANGE
MIN CMD
MAX CMD
BSRACT
ST CUST
LD CUST
DEFAULTS
LD FACT
Fig 14.1
Fig 14.2
Fig 14.3
Fig 14.4
Fig 14.5
A4US
US
A4
US A4
US
A4
