WARNING
Before installing the actuator, make sure that it is suitable for
the intended application. If you are unsure of the suitability
of this equipment for your installation consult Rotork prior
to installation.
WARNING
Protection provided by the equipment may be impaired if used
in a manner not specified by Rotork.
WARNING: ELECTRIC SHOCK HAZARD
Installation and servicing must be performed only by
qualified personnel.
WARNING: ELECTROSTATIC DISCHARGE
This equipment houses static sensitive devices. To protect the
internal components never touch the printed circuit boards
without using electrostatic (ESD) control procedures.
WARNING: ENCLOSURE MATERIALS
CMA actuator castings are manufactured from aluminium
alloy with stainless steel fasteners. The user must ensure that
the operating environment and any materials surrounding the
actuator cannot lead to a reduction in the safe use of, or the
protection afforded by the actuator.
Where appropriate the user must ensure the actuator is
suitably protected against its operating environment.
WARNING: OPERATING BY HAND
Note that under no circumstances should any additional
lever device such as a wheel key or wrench be applied
to the hand-wheel in order to develop more force when
closing or opening the valve. This may cause damage
to the valve and/or actuator and it may also cause the
valve to become stuck in the seated or back seated
position.
WARNING: ACTUATORS WITH LOCAL CONTROLS
Note selection of the 'STOP' position on the Local/
Stop/Remote control knob does not guarantee that the
actuator will lock in place.
ESD and the RPP power failure actions can be
configured to take priority and actuator movement may
occur.
WARNING
The screws securing the outer window frame maintain
the integrity of the flame proof enclosure and must
NOT be removed.
WARNING
Do not remove the top cover assembly or conduit entry
blanking plugs when an explosive environment is
present.
4. Health & Safety
WARNING: RESERVE POWER PACK
Where actuators are supplied with the Reserve Power
Pack assembly please note that the actuator output
shaft may move after removal of the power supply.
WARNING
For actuators fitted with failsafe Reserve Power
Pack only.
The Reserve Power Pack assembly mounted inside the
top cover assembly contains super capacitor cells. Do
not attempt to remove actuator to valve fixings or the
top cover assembly whilst the actuator external local
display is illuminated and/or flashing.
The super capacitors may take up to 30 minutes to
discharge after removal of the power supply and the
LED indicator remains illuminated during this time.
Super capacitors contain toxic/irritant materials. If the
top cover assembly has to be removed for any reason
ensure that the super capacitors are fully discharged
and the area is adequately ventilated prior to removal
of the top cover assembly, allow any vapours to
disperse before gaining entry in to the enclosure.
Use appropriate hand/eye protection and inspect the
super capacitor cells for signs of liquid or gel leakage
before handling.
When working with capacitors ensure adequate
ventilation, protect hands and eyes from contact by use
of Butyl or Neoprene gloves and safety goggles. Wash
hands after handling damaged cells.
Dispose of failsafe Reserve Power Pack module in
accordance with federal, state and local regulations.
A material data sheet is available from Rotork upon
request.
Ensure all LED's on the UPS assembly are extinguished
before removal of the Power pack assembly from the
top cover. If the LED's are illuminated or flashing DO
NOT remove the power pack assembly from the top
cover.
WARNING
The equipment utilizes a non-metallic outer coating and
has a potential static hazard. Clean only with a damp
cloth.
