10. Basic Setup
10.10 Set Command Signal Invert
Press the DOWN arrow until the CMD IV menu is displayed.
Press ENTER until ‘EDIT’ is displayed.
Screen shows Command Signal Invert set to OFF.
Command Signal Invert is adjustable to ON or OFF.
Use the UP/DOWN buttons to set the Command Signal Invert
ON or OFF.
Set to OFF for 4 mA as the close position and 20 mA as the
open position.
Set to ON to invert the signal, 4 mA is open and 20 mA
is close.
Press ENTER to save the current Command Signal Invert
setting.
Press CANCEL to go back to top level menu.
STEP 1
SELECT LOCAL
OPERATION
STEP 2
SET OUTPUT
TORQUE/THRUST
STEP 4
SET CLOSE LIMIT
OF TRAVEL
STEP 5
SET OPEN LIMIT
OF TRAVEL
STEP 6
CALIBRATE COMMAND
SIGNAL ZERO SETPOINT
STEP 7
CALIBRATE COMMAND
SIGNAL SPAN SETPOINT
STEP 3
SELECT ACTION AT END
OF TRAVEL ( LIMIT OR FORCE)
STEP 8
SET COMMAND
SIGNAL INVERT
STEP 9
SET TRANSMITTER
SIGNAL INVERT
STEP 10
DEADBAND
LOCAL
CMD I V
X
X
X
X
EDIT
LOCAL
POS I T
LOCAL
EDIT
C I OFF
LOCAL
EDIT
SAVED
LOCAL
EDIT
C I ON
X
Fig 10.47
Fig 10.48
Fig 10.49
Fig 10.50
Fig 10.51
A4US
US
A4
US A4
US
A4
