Roxell CoMeo - Page 103

ROXELL - 001 - 1020
COMEO - INSTALLATION INSTRUCTIONS
III- 47
MAX. 1/3
MIN. 1/4
MIN. 1/4
MAX. 1/3
Always use hard solder. We recommend a bronze, flux-coated rod. The joint must be well filled. Avoid
sharp edges or rough corners : these wear out the tubes. Braze at low temperature.
Weld
length.
Min.
1
/
4
of the auger circumference, up to
Max.
1
/
3
of the auger circumference.
FIGURE 105.
FIGURE 106.
AUGER BRAZING
