Roxell CoMeo - Poultry Intake Boot with Sensor

To Next Page

To Previous Page

ROXELL-001-2119

COMEO - COMPONENTS

II- 12

* POULTRY INTAKE BOOT WITH SENSOR - 230 V AC - 00108952

** POULTRY INTAKE BOOT WITH SENSOR - 24 V DC - 00108950

Key Name Part Nr. Qt.

1 ANCHOR & BEARING ASS'Y 10111441 1

2 BOOT BODY WELDM F/SENSOR 10112428 1

3 NUT M5 - DIN 934 20100152 2

4 HANDY BOX OBO A8 15000037 1

5 SENSOR DISTANCE PIECE 80 MM 10112436 1

6 LOCKNUT M6 - DIN 985 20100400 4

7 SENSOR HOLDER 13000443 2

*8 SENSOR VC12RT230106821 S3 D1 03103678 1

**8 SENSOR VC12 RTM24106821-2 24-230VAC/DC 03104586 1

9 REINFORCEMENT HOOK 10107597 1

10 TUBE CLAMP ASS'Y ø45 10112037 1

11 BOLT M5X10 DIN 933 20100111 2

12 BOLT M6X12 - DIN 933-8.8 20100160 4

Roxell CoMeo - Poultry Intake Boot with Sensor - 230 V Ac; 24 V DC
