ROXELL - 009 - 2415
COMEO - INSTALLATION INSTRUCTIONS
III-19
FIGURE 34.
TIGHTEN MAIN CABLE
¦15 kg
FIGURE 35.
15cm
+55cm
H
3cm
2cm
L= H+55+2+3+15
15cm
CUT BY MEANS OF A SOLDERING IRON OR AN ELECTRICALLY HEATED KNIFE.
