ROXELL - 001 - 1020
COMEO - COMPONENTS
II- 15
1
2
3
4
5
6
11 12 108 7 9
13
CONTROL UNIT COMEO WITH SWITCH - 00107326
Ke y Nam e Part Nr. Qt.
1 STEPPED ROUND FEEDER PAN 00106953 1
2 SUPPORT CONE F/ CONTROL PA N 00107076 1
3 12 FIN PAN SUPPORT 00108888 1
4 A DJUSTER RING F/ CONTROL PA N 00108896 1
5 TUBE BRACKET ASS'Y 10111893 1
6 HARDWARE KIT 10900322 1
7 SWITCH SHIELD 10111941 1
8 LEVEL SWITCH ASS'Y 13104500 1
9 WOOD SCREW PK Ø4X25-GALVANIZED 20108924 2
10 SUPPORT PLATE FOR LEVEL SWITCH 10111933 1
11 FLEXTUBE KIXoo/VIToo CTRL PAN 15010556 1
12 HINGE JOINT 00101105 1
13 LEVEL SWITCH COMPLETE 00107958 1
00109136: CONNECTION BOX KIT CONTR. PAN
For US only; to be ordered separately
