Roxell CoMeo - To Install the Telescopical Tube

ROXELL - 001 - 1020
COMEO - INSTALLATION INSTRUCTIONS
III- 55
TO INSTALL THE TELESCOPICAL TUBE
FIGURE 125.
Tube clamp
w/S-hook
Chain dia 3,5.
S-hook
Screw link
Cut a hole in the cover at any desired loca-
tion.
100Kg Hopper
Hook for 100kg hopper
FIGURE 126.
FIGURE 127.
=
=
30°
