ROXELL - 001 - 1020
COMEO - COMPONENTS
II- 18
5
4
3
6
2
1
FIXED INTERMEDIATE CONTROL UNIT COMEO -
WITH SENSOR - 00107350
Ke y Nam e Par t Nr . Qt .
1 STEPPED ROUND FEEDER PA N 00106953 1
2 SUPPORT CONE F/ CONTROL PA N 00107076 1
3 12 FIN PAN SUPPORT 00108888 1
4 A DJUSTER RING F/ CONTROL PAN 00108896 1
5 TUBE W/DROP HOLE (2 EXP. ENDS)- L=240MM 10112029 1
6 SENSOR VC12 RT230106821 OFF DELAY 03101185 1
00109136: CONNECTION BOX KIT CONTR. PAN
For US only; to be ordered separately
