Roxell CoMeo - Suspension for Feeder Line

COMEO - INSTALLATION INSTRUCTIONS
ROXELL - 009 - 2416
III-12
FIGURE 14.
MAKE SURE THAT THE MAIN CABLE 5mm DOES NOT HANG IN, BUT BESIDE THE SCREW HOOKS
AND PULLEYS !
SUSPENSION FOR FEEDER LINE
SUSPEND THE CONTROL UNIT AT LEAST 3M FROM THE HOUSE END WALL !
FIGURE 15.
00100388
MAIN CABLE
MAIN CABLE MAIN CABLE
