Roxell CoMeo - Fixed Intermediate Control Unit Comeo with Switch

ROXELL - 001 - 1020
COMEO - COMPONENTS
II- 17
5
4
7 9
3
2
1
6 8
11
10
FIXED INTERMEDIATE CONTROL UNIT COMEO -
WITH SWITCH - 00107342
Key Nam e Part Nr. Qt.
1 STEPPED ROUND FEEDER PAN 00106953 1
2 SUPPORT CONE F/ CONTROL PAN 00107076 1
3 12 FIN PAN SUPPORT 00108888 1
4 ADJUSTER RING F/ CONTROL PAN 00108896 1
5 TUBE W/DROP HOLE (2 EXP. ENDS)- L=240MM 10112029 1
6 LEVEL SWITCH ASS'Y 13104500 1
7 PLATE SWITCH 10112005 1
8 SWITCH SHIELD 10111941 1
9 WOOD SCREW PK Ø4X25-GALVANIZED 20108924 2
10 FLEXTUBE KIXoo/VIToo CTRL PAN 15010556 1
11 LEVEL SWITCH COMPLETE 00108038 1
00109136: CONNECTION BOX KIT CONTR. PAN
For US only; to be ordered separately
