Roxell CoMeo - Extension Feed Intake Boot; Flexible Connection Box

ROXELL - 001 - 1020
COMEO - COMPONENTS
II- 32
EXTENSION FEED INTAKE BOOT - 00901470
4
3
76
5
1
2
8
10
9
Ke y Nam e Par t Nr . Qt .
1 SIDE PLATE EXTENSION BOX 10900397 2
2 FRONT&BACK PLATE EXTENSION BOX 10900389 2
3 TOP PLATE EXTENSION BOX 10900405 1
4 NUT M6 - DIN 934 20100210 12
5 SOCKET CAP SCREW M5X10 - DIN 912 20103149 2
6 LOCKNUT M5 - DIN 985 20100392 2
7 "S" HOOK 05000013 2
8 SOCKET CAP SCREW M6X10 - DIN 912 20101713 12
9 HOSE CLAMP Ø90-110 00105726 2
10 PARCKER SCREW 8X1/2" 20100525 1
FLEXIBLE CONNECTION BOX - 00106757
