Roxell CoMeo - Control Panel Intermediate Control Unit (with Sensor)

COMEO - INSTALLATION INSTRUCTIONS
ROXELL - 009 - 4016
III- 36
FIGURE 77.
Cable
1 2
3
CONTROL PANEL INTERMEDIATE CONTROL UNIT (WITH SENSOR)
FIGURE 78.
For an “easy use”, and/or switching over from a partial area to full use of the house, you can make advant-
age of a control panel intermediate control unit ( (optional).
1 intermediate control unit
2 intermediate control units
control unit with sensor (at the end)
1and2
Position of the switch
1 or 2, depending on the brooding area in the house
E
Use of
OFF
STARTSTOP
