COMEO - INSTALLATION INSTRUCTIONS
III-13
CONSIDER THE DOUBLE DIVERSION !! ONLY THEN INSTALL THE CABLE. YOU CAN HANG THE
MAIN CABLE IN THE SCREW HOOKS FOR T HE TIME BEING.
- Measure the distance from the wall to the first feeder line.
- Mark from this spot the suspension points on the ceiling over the whole length of the line.
Alternat ives : see page III-8
FIGURE 16.
MAIN CABLE
CENTRAL WINCH
FIGURE 17.
00104349
05000872
3m 3m
FIGURE 18.
FIGURE 19.
00100412
00100412
3m
3m
