Roxell CoMeo - Page 109

ROXELL - 001 - 1020
COMEO - INSTALLATION INSTRUCTIONS
III- 53
FIGURE 121.
00400077
To stretch min. 50mm / max. 65mm.
Cable tie.
After all cables for poultry perch have been installed, connect the poultry perch guard to the
1
/
16
”
cable.
FIGURE 122.
Socket
Poultry perch guard
Earthing
Earthing (per line)
Important : use only cable for poultry per-
ch (ignition cable 1mm
2
)
.
POULTRY PERCH GUARD AND FEEDER LI
NE MUST BE EARTHED !!!
