Roxell CoMeo - Page 42

ROXELL - 001 - 1020
COMEO - COMPONENTS
II- 20
1
2
3
4
5
MOVABLE INTERMEDIATE CONTROL UNIT COMEO -
WITH SENSOR - 00107398
Key Name Part Nr. Qt.
1 STEPPED ROUND FEEDER PA N 00106953 1
2 SUPPORT CONE F/ CONTROL PA N 00107076 1
3 12 FIN PAN SUPPORT 00108888 1
4 A DJUSTER RING F/ CONTROL PA N 00108896 1
5 SENSOR VC12 RT230106821 OFF DELAY 03101185 1
00109136: CONNECTION BOX KIT CONTR. PAN
For US only; to be ordered separately
