Roxell CoMeo - Page 66

COMEO - INSTALLATION INSTRUCTIONS
ROXELL - 009 - 2416
III-10
FIGURE 10.
install the central winch somewhat out of line.
Cable
Feeder line.
25cm15cm 25cm 25cm 25cm15cm 15cm 15cm
0cm 0cm
CHOOSE BETWEEN 2 FOLLOWING POSSIBILITIES (SO THE CABLE CLAMPS WILL NOT TOUCH THE
PULLEYS WHEN YOU WINCH UP THE LINE).
FIGURE 11.
Place suspension hooks crosswise off the beam center line.
00100388
MAIN CABLE
MAIN CABLE MAIN CABLE
