4.4 Reserved Interface HMI
HMI is a factory interface whose function is reserved to user.
4.5 Udisk Interface
Udisk interface is a USB-AM, by this interface; the controller can read/write all kinds of
U-discs.
4.6 USB Interface
USB interface is a USB-BM, which the controller can communicate with PC by USB2.0.
4.7 Ethernet Interface
Using this interface, the controller can communicate with PC by 10/100MHZ Ethernet.
Pin to Pin Ethernet parallel line is recommended.
Caution
