4.12 Water Protect Input Interface CN5
Water protect input interface CN5 (5Pin, 3.81mm space):
Pin
Symbols
Definitions
1
LGND
Laser power 5V ground (output)
2
WP1
The input port of water protector for the first laser power
source. When the water protector 1 is enabled, the controller
will detect the input port of water protector 1. If this port is
of low level, it will be deemed normal; if this port is of high
level, the controller will forcibly close the laser to suspend
the work in progress and the system will warn. If the water
protector 1 is not enabled, the controller will not detect the
input port of water protector 1 and the user not connect the
water protector 1.
3
WP2
The input port of water protector for the second laser power
source. When the water protector 2 is enabled, the controller
will detect the input port of water protector 2. If this port is
of low level, it will be deemed normal; if this port is of high
level, the controller will forcibly close the laser to suspend
the work in progress and the system will warn. If the water
protector 2 is not enabled, the controller will not detect the
input port of water protector 2 and the user not connect the
water protector 2.
4
L-IN3
General input with the function reserved.
5
L5V
Laser power 5V positive (output)
