Page #14 background imageLoading...
Page #14 background image
RDC6332G Control System User Manual
14
/
47
© 2015 Ruida Technology. All Rights Reserved
4.8 General Output Port CN2
Definition of general output port (6Pin, 3.81mm space)
Pin
Symbols
Definitions
1
OGND
External power ground (output)
2
Out4
General output 4, with the function reserved.
3
Out3
General output 3, with the function reserved.
4
Out2
General output 2, and the signal port of operating status. If
this port is externally connected with the relay, the relay coil
is broken over when it works; no influence is produced
when it suspends working. When its work ends or is
stopped manually, the relay coil will be cut off.
5
Wind
General output 1. When the blower control is enabled, this
port will output the control signal of the blower, otherwise it
will output other special control signals. When the blower is
connected and its control enabled, the blower switch can be
set separately on each layer. If the relay is connected
externally, the relay coil will be broken over when the
blower is on; the relay coil will be cut off when the blower
is off.
6
O 24V
External power output (If the interface of main power
source is powered with 24V power supply, this pin should
be 24V; if it is powered with 36 V power supply, this pin
should be 36V.)
All outputs are isolated through the opto-isolator, and 500mA
current for each, OC gate output, each can directly drive the 6V/24V
relay.
Prompt
