RDC6563F Standalone Fiber Cutting Control System User Manual V2.0 19
SHENZHEN RUIDA TECHNOLOGY CO., LTD
signal
definition
Description
+24V
+24V power input
controller+24V power input, Power supply
current output capability is greater than 3A
GND
GND
—
PG
External shield
Generally connected to the earth or the
shell
2.4 HMI interface
HMI is DB9 interface, the manufacturer's special shielded cable to connect mainboard and
HMI.
Important:
Do not use hot plug the DB9 terminal during to avoid damage to
internal components.
2.5 PC-USB interface
PC-USB is USB-BM port.It is the interface that the motherboard and PC access through
USB2.0.Connect PC from USB cable. If using USB to connect the controller, please set to USB
from RDCutist software. If you are the first time connect the controller in this PC, you should
install the USB driver, about USB driver Installation details. Please refer to the "Device
Connection" section for instructions.
2.6 U-disk interface
U-disk is USB-AM port，it is the port for mainboard access the U disk, it can copy standalone
files. The capacity of the U disk is generally less than 8G. Otherwise, the read and write speed
may be too slow or even the U disk may not be recognized.
Important:
Please pay attention to the USB interface on the panel and the
Udisk interface on the mainboard. The USB interface on the panel
is used for panel firmware upgrade. The U-disk interface on the
motherboard is used for copying standalone files.
