2.16 Indicator Description
Type
Definition
Description
X AXIS
LMT+
X-axis positive limit indicator
When the input port is low voltage,
the indicator is on.
LMT-
X-axis negative limit indicator
When the input port is low voltage,
the indicator is on.
ALM
X-axis servo drive alarm
indicator
When the input port is low voltage,
the indicator is on.
SON
X-axis servo drive enable
indicator
When the input port is low voltage,
the indicator is on.
+5V
+5V Power Indicator
When the system power is normal,
the indicator is on.
ERR
System error indicator
When the mainboard hardware
fails, the indicator light is on.
RUN
System operation indicator
When the system is running
normally, the indicator light flashes
at a frequency of 2 seconds/time.
Y1/Y2 AXIS
LMT1+
Y1 axis positive limit indicator
When the input port is low voltage,
the indicator is on.
LMT1-
Y1 axis negative limit
indicator
When the input port is low voltage,
the indicator is on.
ALM1
Y1 axis servo drive alarm
indicator
When the input port is low voltage,
the indicator is on.
SON1
Y1 axis servo drive enable
indicator
When the input port is low voltage,
the indicator is on.
LMT2+
Y2 axis positive limit indicator
When the input port is low voltage,
the indicator is on.
LMT2-
Y2 axis negative limit
indicator
When the input port is low voltage,
the indicator is on.
ALM2
Y2 axis servo drive alarm
indicator
When the input port is low voltage,
the indicator is on.
SON2
Y2 axis servo drive enable
indicator
When the input port is low voltage,
the indicator is on.
U/A AXIS
U-LMT+
U-axis positive limit indicator
When the input port is low voltage,
the indicator is on.
U-LMT-
U-axis negative limit indicator
When the input port is low voltage,
