the indicator is on.
U-ALM
U-axis servo drive alarm
indicator
When the input port is low voltage,
the indicator is on.
U-SON
U-axis servo drive enable
indicator
When the input port is low voltage,
the indicator is on.
A-LMT+
A-axis positive limit indicator
When the input port is low voltage,
the indicator is on.
A-LMT-
A-axis negative limit indicator
When the input port is low voltage,
the indicator is on.
A-ALM
A-axis servo drive alarm
indicator
When the input port is low voltage,
the indicator is on.
A-SON
A-axis servo drive enable
indicator
When the input port is low voltage,
the indicator is on.
Z AXIS
LMT+
Z axis lower limit indicator
When the input port is low voltage,
the indicator is on.
LMT-
Z axis upper limit indicator
When the input port is low voltage,
the indicator is on.
ALM
Z axis servo drive alarm
indicator
When the input port is low voltage,
the indicator is on.
SON
Z-axis servo drive enable
indicator
When the input port is low voltage,
the indicator is on.
LINK
Network connection indicator
This indicator lights up when the
Ethernet is connected.
ACT
Network communication
indicator
This indicator lights up when
communicating
LASER
ENABLE
Reserved
—
SHUTTER
Shutter status indicator
When the shutter is off, the
indicator lights up.
GUIDE
Reserved
—
ALM
Laser machine alarm input
indicator
When the input port is in low
voltage, the indicator is on.
LASER
Laser machine PWM signal
indicator
When PWM signal output, the
indicator lights up
IO
OUT1～
OUT15
General purpose output IO
indicator
When the output port in low
voltage, the indicator is on.
