3.3 Main interface function
The main interface will be displayed when the system power-on reset is completed. As
shown below:
25
Manually move the U axis.
26
Set the anchor point.
27
Used for return to the previous menu, cancel parameter
settings, etc.
28
Used for enter the next level menu, operation confirmation,
etc.
29
Switch between numeric and alpha input modes.
30
Decimal point.
31
Used for delete parameters.
32
～
Enter a number or letter. Press the number 0 under system
idle to return to the stop.
