HMI, when the input port is triggered, the motion of
the machine stops.
I10
External laser input
Dedicated input, it is laser hardware switch input
port, when connected to low voltage, laser spotting
can be run, when high voltage, no laser.
I11
Gas alarm input
Dedicated input, used for gas detection alarm input
port. When input voltage level, gas alarm, and the
main board will stop cutting.
I12
General input IO
Reserved
I13
General input IO
Reserved
I14
General input IO
Reserved
I15
General input IO
Reserved
GND
General input IO
—
Important:
All input IO pins are compatible with 5V Or 24V inputs.
2.15 General Output IO
General output IO interface definition, as shown in the following table:
Signal
Definition
Description
Q1
General output IO
Buzzer control signal, low voltage valid
Q2
General output IO
Tricolor lamp control: Green light control
signal, low voltage valid
Q3
General output IO
Tricolor lamp control: yellow light control
signal, low voltage valid
Q4
General output IO
Tricolor lamp control: red light control
signal, low voltage valid
Q5
General output IO
Status output
Q6
General output IO
Reserved
Q7
General output IO
Reserved
Q8
General output IO
Gas 1 control signal, low voltage valid, it
can control the relay to control the
solenoid valve directly
