RDC6563F Standalone Fiber Cutting Control System User Manual V2.0 49
SHENZHEN RUIDA TECHNOLOGY CO., LTD
Manual slow U
Refers to the speed at which the U axis is manually
moved when [speed is slow].
Manual fast A
Refers to the speed at which the A-axis is manually
moved when [Speed].
Manual slow A
Refers to the speed at which the A-axis is manually
moved when [Slow].
Reset
parameter
X reset speed
Speed when X-axis is reset
Y reset speed
Speed when Y axis is reset
Z reset speed
Speed at Z-axis reset
U reset speed
Speed when U axis is reset
A reset speed
Speed when A axis is reset
X power-on reset
enable
If the X-axis power-on reset is enabled, the Z-axis will be
automatically reset when the machine is turned on,
otherwise it will not be reset automatically.
Y power-on reset
enable
If the Y-axis power-on reset is enabled, the Z-axis will be
automatically reset when the machine is turned on,
otherwise it will not be automatically reset.
Z power-on reset
enable
If the Z-axis power-on reset is enabled, the Z-axis will be
automatically reset when the machine is turned on,
otherwise it will not be automatically reset.
U power-on reset
enable
If the U-axis power-on reset is enabled, the Z-axis will be
reset automatically when the machine is turned on,
otherwise it will not be reset automatically.
A power-on reset
enable
If the A-axis power-on reset is enabled, the Z-axis will be
automatically reset when the machine is turned on,
otherwise it will not be reset automatically.
Other
parameters
Return position
The position where the laser head is stopped after
processing is completed. There can be four kinds of
mechanical origin, positioning point, no return, and back
stop.
Frame mode
The movement mode when the panel starts the frame
movement. It can be related to the light walking border,
the light walking border and the four corners.
Go scale blank
distance
The distance of the frame motion track relative to the
actual graphic frame.
Dock X position
Used to set the X-axis coordinate position of the stop.
Dock Y position
Used to set the Y coordinate position of the stop.
