RDC6563F Standalone Fiber Cutting Control System User Manual V2.0 52
SHENZHEN RUIDA TECHNOLOGY CO., LTD
with a large inertia, such as the Y axis corresponding to
the beam, a typical setting range is 800 to 3000 mm/s2,
which corresponds to an axis with less inertia. For the
corresponding X axis, a typical setting range is 8000 to
20000 mm. /s2.
The acceleration value when the button moves the axis
movement cannot be higher than the maximum
acceleration of the axis.
Emergency stop
acceleration
If the axis is enabled for hard limit protection, when the
axis moves to the limit position, the axis will be
emergency deceleration and stop operation with an
emergency stop acceleration. This value can take 2 to 3
times the maximum acceleration of the axis.
If the hardware limit is enabled, when the hardware limit
is triggered, the limit protection will be generated. If the
hardware limit is disabled, the protection will not occur
when the hardware limit is triggered.
If the machine is equipped with this axis, the [Reset
Enable] option of the axis should be turned on. If the axis
is not used, the [Reset Enable] option of the axis should
be disabled.
Pulse rising edge
is valid
The pulse signal used to set the motor driver is valid for
the rising edge or the falling edge. When the item is not
enabled, the controller uses the falling edge. When the
item is enabled, the controller uses the rising edge.
If the servo alarm is enabled, protection will be generated
when the servo drive alarms; if the servo alarm is
disabled, no protection will be generated when the servo
drive alarms.
Used to control the direction of motion when the manual
button moves the motion axis. When the direction
polarity parameter is correctly set, if the direction key is
pressed on the operation panel and the axis moves in the
opposite direction, the reverse button can be enabled.
Checking this option has two Y-axis output channels Y1
and Y2 for use on machines with bilateral gantry
structures. This parameter has only the Y1 axis
parameter, and the other axes are not. After setting, Y1
