RDC6563F Standalone Fiber Cutting Control System User Manual V2.0 54
SHENZHEN RUIDA TECHNOLOGY CO., LTD
triggered, no protection will be generated.
If the servo alarm is enabled, protection will be generated
when the servo drive alarms; if the servo alarm is
disabled, no protection will be generated when the servo
drive alarms.
It is used to set the capacitance value of the nozzle when
it touches the plate. This parameter must be set correctly,
otherwise, it may happen that the plate is touched
repeatedly or the collision alarm is mistakenly triggered
when the film is calibrated. When setting this parameter,
manually move the z-axis to move the nozzle to the
height that just touches the metal plate, and the
capacitance value displayed on the plate is the value of
the colliding plate capacitance.
Laser type can choose fiber laser, glass tube and RF
tube, please according to the actual situation of the
machine enable laser.
For non-fiber lasers, the pre-ignition mode can be used.
When it is a radio frequency laser and a pre-ignition
pulse is required, the characteristics of the pre-ignition
pulse can be configured by the pre-ignition frequency
and the pre-ignition pulse width.
When it is a radio frequency laser and a pre-ignition
pulse is required, the characteristics of the pre-ignition
pulse can be configured by the pre-ignition frequency
and the pre-ignition pulse width.
The system limits the maximum power that the laser can
output.
The system limits the minimum power that the laser can
output.
Laser PWM output signal frequency.
Set the laser ON signal logic level
When the laser alarm is enabled, when the laser
generates an alarm, the motherboard will generate
protection, otherwise it will not be protected.
When the signal is externally input, it can be connected
to external devices such as water tanks and sliding
