Ryobi RYRM8010 - Page 10

10
Component Locations
< Return to Table of Contents
RYRM8021 42” ZTR Mower
RYRM8034 54” ZTR Mower
Access Port*
under seat
Charging Port
Brake Switch
*NOTE
Beeper, Drive Motor Controllers,
Deck Motor Controllers
, and TIC
are accessed via the Access Port.
Battery Booster
under Battery Box
DC-DC Converter,
Main Relay
,
& Mixing Board
iDRIVE Joystick
LCD Panel Display
Headlights
Seat Switch
under seat
Confidential and Proprietary - Property of Techtronic Power Equipment - DO NOT COPY or DISCLOSE
Control Panel
