RYTEC System 3 User Manual

27
SYSTEM STARTUP—FAULT CODES
Door Safety/Emergency System Fault Codes
Table 5 below lists possible fault codes associated with
the door safety/emergency system. Included in this
table is a description of each fault code and the sug-
gested, corrective action. (The door is in the emergency
stop mode and will not operate.)
Table 5
Reversing Edge Circuit Fault Codes
Table 6 below lists possible fault codes associated with
the reversing edge circuit. Included in this table is a
description of each fault code and the suggested, cor-
rective action. (Door is in the error jog only mode.)
Table 6
Fault Code
(Safety/Emergency)
Description Corrective Action
F.2 01 Internal emergency stop or control system
watchdog activated.
1. door stopped and does not operate
2. corresponding error message is
displayed
1. check internal E-stop jumper
2. consult factory if watchdog is activated
F.2 11 External Emergency Stop 1 activated.
1. door stopped and does not operate
2. corresponding error message is
displayed
1. reset E-Stop 1
2. reset E-Stop 1
F.2 12 External Emergency Stop 2 activated.
1. door stopped and does not operate
2. corresponding error message is
displayed
1. reset E-Stop 2
2. reset E-Stop 2
Fault Code
(Reversing Edge)
Description Corrective Action
F.3 60 Does not apply. Consult factory.
F.3 61 Reversing edge tripped.
1. bottom edge of door came in contact with
object in door opening
2. short in reversing edge wiring
3. pressure switch faulty or not adjusted
1. reset control system
2. check and repair wiring
3. check and adjust switch
F.3 62 Internal control check. Consult factory.
F.3 63 Reversing edge circuit open.
1. reversing edge wiring disconnected
2. reversing edge coil cord cut or damaged
3. reversing edge resistor is wrong value or
missing
Check all parts of reversing edge circuit
including coil cord and resistor. Make any
necessary repairs or adjustments. Verify
proper operation of reversing edge after
all repairs and adjustments are made.
F.3 64 Does not apply. Consult factory.
