RYTEC System 3 User Manual

18
SYSTEM STARTUP—PARAMETERS
Service Level 2 Parameters
Table 3 below lists the parameters available through
Service Level 2. Included in this table is a description of
each parameter, and its available range and factory
default setting.
Table 3
Parameter Range Service Level 2 Parameters Factory
Setting
P. 0 00 Door cycle counter (read only)
P. 0 10 0 – 200 seconds Auto-close delay timer 1 – ACL1 (with activator connected to
input 5 – terminal 14)
0 = off
10
P. 0 11 0 – 200 seconds Auto-close delay timer 3 – ACL3 (used with optional passage
position only)
0 = off
0
P. 0 15 0 – 200 seconds Auto-close delay timer 2 – ACL2 (with activator connected to
input 6 – terminal 16 or input 7 – terminal 18)
0 = off
5
P.050
(Defrost
System Only)
0 – 3 Heater status
0: off
1: on – low heat stage 1 heated blower or heat lamps
2: on – medium heat stage 1 + 2 heated blower
3: on – high heat stage 1 + 2 + 3 heated blower
0
P.051
(Defrost
System Only)
0 – 1 Heater control (parameter 050 must be on)
0: manual
1: automatic timer
0
P.055
(Defrost
System Only)
0 – 3 Blower control
0: off
1: low speed
2: high speed
3: automatic (blower runs at high speed when door is open)
0
P.058
(Defrost
System Only)
5 – 600 minutes Heater timer on time 30
P.059
(Defrost
System Only)
5 – 600 minutes Heater timer off time 5
P. 0 70
(Clean-Roll
Door Only)
0 – 1 Clean position (for cleaning panel and drum assembly)
0: off
1: cleaning position (press close key with door closed)
10
P. 1 00 30 – 200 Hz Motor frequency (listed on nameplate) 60Hz
P. 1 01 0 – 9.9 amps Motor current (listed on nameplate)
P. 1 02 40 – 100% Motor power factor (listed on nameplate)
P. 1 03 100 – 500 Motor voltage (listed on nameplate)
P. 1 40 0 – 30% Torque boost – door-open cycle 0
